HAVN HS 360 White Panoramic Glass ATX Case
HAVN

HAVN HS 360 White Panoramic Glass ATX Case

SKU: HVN-CA-HS360-01
Out of Stock
€210,95
€210,95 - €210,95
€210,95 - €210,95
€210,95
Inc VAT
Delivery Truck
Free Standard Delivery or £5 Off Royal Mail and Parcelforce Delivery Available on UK Orders Over £75 - Excludes Large Items and PCs Read More
TrustScore: 4.8 / 5
★★★★★
See Our Reviews on Trustpilot

The HAVN HS 360 is a white ATX mid tower PC case with panoramic tempered glass. It supports ATX, BTF ATX (Back Connect), Micro-ATX and Mini-ITX motherboards, and has a 61.9 L internal volume. That is 19.4% smaller by volume than the HAVN HS 420 (76.8 L), and it still accommodates long GPUs, large radiators and up to eleven 120 mm fans.

Key Features

  • Panoramic glass: UniSheet panoramic tempered glass with a 7.5 mm bend radius, with roller alignment to assist fitting.
  • Back Connect ATX: supports BTF ATX motherboards and can be switched between standard and back-connect modes.
  • Radiator support: 360 mm radiators at the top, right and bottom, subject to thickness and component limits.
  • Fan support: up to eleven 120 mm fans (3 top, 3 right, 3 bottom, 2 rear), with rear fans up to 30 mm thick.
  • GPU support: horizontal mounting with 7 expansion slots, for GPUs up to 430 mm long and 180 mm wide.
  • Cable management: SimpliCable routing and an 8-channel PWM fan hub in the cable management tray.
  • Dust filtration: built-in top and right filters, with removable bottom and rear-bottom filters.

Front I/O

  • 1 × USB 3.2 Gen 2 Type-C
  • 2 × USB 3.2 Gen 1 Type-A
  • 1 × combo audio jack
  • 1 × power button

Build Notes

HAVN's in-house testing records an approximately 36% increase in structural strength over the HS 420. The case includes two storage bays and a VESA mount for a display in the front right pillar, supporting 75 × 75 mm and 100 × 100 mm patterns. The HS 360 carries a 1-year warranty.

General

BrandHAVN
ModelHS 360
ColourWhite
Manufacturer part numberHVN-CA-HS360-01
EAN4251442514235
UPC842946114232
Form factorMid tower
MaterialSGCC sheet metal, tempered glass, ABS, nylon, zinc alloy, NdFeB magnets
Dimensions (L × W × H)490.9 × 242.1 × 520.9 mm
Internal volume61.9 L
Net weight12.7 kg
Gross weight14.04 kg
Warranty1 year

Motherboard

Supported form factorsATX, BTF ATX (Back Connect), Micro-ATX, Mini-ITX
Expansion slots7

Cooling and Memory

CPU cooler max height170 mm (liquid cooling recommended)
RAM max height with AIO46 mm, plus 2.5 mm clearance
Top radiator360 mm (65 mm thick, does not overlap RAM)
Right radiator360 mm (58 mm thick with GPU over 300 mm; 90 mm with top AIO)
Bottom radiator360 mm (109 mm with 1-slot GPU; 120 mm with GPU support removed)
Fan supportUp to 11 × 120 mm (3 top, 3 right, 3 bottom, 2 rear)
Rear fan max thickness30 mm
PWM fan hub8 channels, in cable management tray

GPU and PSU

GPU mountingHorizontal, 7 slots
GPU max length430 mm
GPU max width180 mm
GPU slot clearanceFrom 2nd slot: up to 5-slot GPU; from 3rd slot: up to 4-slot GPU
PSU typeATX / SFX / SFX-L
PSU max length230 mm (300 mm clearance)

Storage and Display

Storage bays included2
Storage capacity (2-bay setup)2 × 3.5-inch / 4 × 2.5-inch
Storage capacity (1-bay setup)1 × 3.5-inch / 2 × 2.5-inch
VESA mounting75 × 75 mm / 100 × 100 mm
Display area (H × W)425 × 140 mm
Display locationFront right pillar

Front I/O

USB ports1 × USB 3.2 Gen 2 Type-C, 2 × USB 3.2 Gen 1 Type-A
Audio1 × combo audio jack
Power button1

Panel, Airflow and Cable Management

Glass panelUniSheet panoramic tempered glass, 7.5 mm bend radius
Dust filtersBuilt-in: top, right. Removable: bottom, rear bottom
Cable managementSimpliCable routing
